Obsolete: 1/8 DIN LED Readout
NOTE: This digital readout is no longer available. Use #700-1600-091 instead.
This easy to see Red LED In-Panel Readout is an ideal choice for OEM applications. This Readout has rear facing Encoder input, bus connections and signal outputs. There are 3 independent measurement reference modes plus RS485 output. This Readout operates on 14-24 VDC.
Out of stock
SKU
700-1600-090
$329.00
Product or Custom Design Question
Features:
- Power: 14-24 VDC
- Easy-to-read: Red LED Readout
- Displays: decimal inches or millimeters
- Easy mounting: fits 1/8 DIN cutout
- References: 3 independent Datum points
- Scaling Factor: linear multiplier
- Programmable: Upper and Lower Limits
- Selectable: Limit Output (Normally Open or Normally Closed)
- RS485: Selectable bus address, baud rate and data output (streaming or request)
- Lock-Out: Front panel keys and Readout programming
- RoHS compliant: Lead Free Product
- MADE IN USA
Specifications:
inch | mm | ||
Display Range | ± 999.999 | ± 9999.99 | |
Resolution | .1, .01 or .001 | .1 or .01 | |
Repeatability | .001 | .01 | |
Operating Power | 14-24VDC @ 50mA | ||
Output | RS485 | ||
Dimensions | 3.79 x 1.93 x 3.02 in. (97 x 49 x 77 mm) | ||
Current Part Number | 700-1600-090 | ||
Current Firmware version | 3.xx |
